EGO Heating Elements 20.17983.000

Home / EGO PRODUCTS / EGO Heating Elements 20.17983.000

EGO Heating Elements 20.17983.000

AED 225.00 (Inclusive of VAT)
If you've found a better price, give us a heads up on 055 551 9890 / Send Email, & we will beat it! *T&C apply
Quantity:

    • Power: 2500 w
    • Voltage: 230 v
    • Length: 255 mm
    • Length 1: 55 mm
    • Width 1: 25 mm
    • Height 1: 2 mm
    • Height 2: 18 mm
    • Mounting: rectangular flange with thread bolt
    • Connection: male faston 6.3mm
    • Tube diameter: 6,3 mm
    • Heating circuits: 1
    • Hole distance: 36 mm
    • Internal diameter: 183 mm
    • External diameter: 195 mm
    • Height: 20 mm
    • Flange length: 47 mm
    • Flange width: 17 mm
    • Mounting thread: m4
    • Application: Convection heating element


BrandEGO
Lead Time READY STOCK

We specialize in the design, development, and production of top-tier custom-made Heavy Duty Marine, Industrial & Commercial Grade Heaters in the UAE
