Temperature max.
190 °C
Number of poles
3 -pole
Function
1CO/2NO
Switching capacity
16 A
Probe diameter
4 mm
Probe length
157 mm
Capillary pipe length
1780 mm
Gland nut
-
Shaft diameter
ø6x4.6 mm
Operating temperature range
106-190 °C
Capillary pipe length insulated
1500 mm
Shaft length
23 mm
Rotation angle
270 °
Producer
EGO
Series
55.34_
Shaft position
upper
Weight
0,180 kg
